*Price from: CA$ 102,178.00 ($170/Sq.Ft)
​Transportation: 1x 40’HC
(Optional 1x 20’DC as per final specifications)
Delivery: port of Montreal, QC, CANADA
(TAX not included*)
House kit includes:
External wall elements
• Horizontal wooden boarding UYV 21x145 mm – fine sawn, once primed, once painted, installation with stainless steel nails, installed at factory as much as possible
• Vertical ventilation battens 30x45 mm
-Rodent-net for the perimeter of the house
• Wind protection membrane
• OSB-3.12 mm
• Wooden frame 45x195 mm, cc 600
-Mineral wool insulation, 200 mm (λ = 0.035 W/mK)
• OSB 12 mm
• Wooden subframe 45x45 mm, cc 600
• Construction paper / strings / plastic bands, to hold insulation in place
​
​​Not included:
-Insulation, 50 mm (λ = 0.035 W/mK) – not included
-Electrical boxes and conduits – not included
-Gypsum board – not included
Roof materials
• Sheet metal roofing, Klassik GreenCoat PURAL BT Z350 0,50mm RR32 (dark brow) + installation accessories and rainwater evacuation system
• Roofing battens 28x95, cc 200
• Ventilation battens 45x45 mm, cc 600
• Roof underlay Klöber TDSH Ecovent145 , breathable
• Precut rafters 45x195, cc 600
• Precut laminated purlin 160x360 mm
Not included:
-Roof accessories (snow guards, walkways, ladder) standard colour - not included
​
Ceiling materials between and under rafters​
• Underroof battens 28x70 mm, cc 400
Not included:
​ -Insulation – not included
-Vapour protection layer - not included
-Ceiling gypsum board, 13mm – not included
Internal wall elements
• OSB-3.12 mm
• Wooden frame 45x95 mm, cc 600
-Mineral wool insulation, 100 mm (λ = 0,035 W/mK)
• Construction paper / strings / plastic bands, to hold insulation in place
​Not included:
-Electrical boxes and conduits – not included
-Gypsum boards on both sides – not included
Eaves materials
• Insect net
• Eaves boarding 21x120/145 mm – fine sawn, once primed, once painted - delivered as loose
material
• Eaves’ underside boarding 18x95 mm – without finishing - delivered as loose material
Windows and doors
• Windows and terrace door: PVC, triple glazed, Eiche Dunkel inside/ Eiche Dunkel outside
• Installation of doors and windows into elements at factory, where possible
• Window flashings (aluminium), under openings
• Trims outside
• External wooden door (1 pce), RAL8014 Sepia brown, triple glazed, inwards opening, 3-point lock
​
​​Not included:
-Internal doors – not included
Additional materials / works included
• Impregnated base timber 45 x 95/145/195 mm
• Socle seal between external walls and foundation
• External angle covering vertical boards- fine sawn, once primed, once painted
• Mineral wool bands installed between and under elements
• Four laminated wooden purlin supporting posts 160x160 mm
• Constructive fixing materials D >= 8mm / special connectors
• Weatherproof packing of elements at factory and loading onto trucks
• Project documentation – Approval documents, Assembly manual, packing list, Phytosanitary Certificate if needed
​
Offer does not include:
-Internal finishing materials
-Special works - heating, ventilation, electrical, plumbing
-Any other material or work not described in price offer
